Available for pre-order Feb 28th

The Loop TKL

The next generation of the tenkeyless form factor from Mode. Configure Yours

A Closer Look at the Prototype

Loop sounds and features
Refined Accents

The Loop features a new split ring design joining the top and bottom halves together, looping around the periphery of the board for a subtle and elegant accent. An accent strip across the forehead of the board and a solid weight mounted underneath the board round out the refined accents in this board.

Lattice Block Mount System

Loop uses a split ring multi-component chassis design that sandwiches the lattice blocks within the inner ring. The thick top skin of the lattice blocks acts as a "force break", isolating the metal top case and ring from each other for a reduction of resonance between the chassis components.

Extensive Customization

Featuring returns of classic colors and materials such as cream, copper, mirage, and silver mirror the loop will also feature a new elderberry colorway as well as the revival of the black mirror finish.

Refined Accents
Lattice Block Mount System
Extensive Customization

FAQ

The Loop TKL will be available for pre-order on February 28th at 1:00PM EST.

Pricing for Loop begins at $299, with final costs varying based on the selection of additional options and extras.

The Loop pre-order units are already en-route to Mode with fulfillment planned to begin in April. After all pre-orders are fulfilled the board will move into "In-stock" status.

6.25u/7u Bottom Row, Standard/Stepped Capslock, Split Right Shift (Solder Only), Split Backspace (Solder Only) ISO (Solder Only)

The Mode Loop TKL makes use of the Lattice Block mounting method that was introduced on the Envoy and Tempo keyboards with some improvements based on user feedback. Instead of using retaining fasteners to keep the PCB and Plate from falling out of the board when tipped upside down, Loop uses a split ring multi-component chassis design that sandwiches the lattice blocks within the inner ring.

The thick top skin of the lattice blocks acts as a "force break", isolating the metal top case and ring from each other for a reduction of resonance between the chassis components.

Technical Specs

Measurements

Typing Angle: 5.8 Degrees

Front Height: 19.5mm

Dimensions: 365mm x 147mm x 32mm

Weight: 3.5-7lbs

PCB & Layout

Thickness: 1.6mm

Switches: 86-89

Firmware: QMK with VIA support

MCU: ARM

Materials

Case: Aluminum

Accent: Aluminum, Brass, Copper

Weight: Aluminum, Brass, Copper

Plate: Aluminum, POM, Carbon Fiber, Copper, FR4

Box Contents

Keyboard Case

Feet and Mounting Blocks

PCB + Daughterboard

Carry Case

Screwdriver

Keycap and Switch Puller

Various Fasteners
